China Dongguan Tai Fu Machinery co., LTD logo
Dongguan Tai Fu Machinery co., LTD
One-stop vertical injection molding machine all-day solution, Achieve employees internally and customers externally, Efforts to promote Chinese injection molding equipment to the international market.
Active Member

2 Years

Home > High Speed Vertical Injection Molding Machine >

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

Dongguan Tai Fu Machinery co., LTD
Contact Now

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

Brand Name : TAIFU

Model Number : TFV4-55-SP

Certification : CE,ISO9001

Place of Origin : Dongguan, China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 230 sets/month

Delivery Time : Negotiable

Packaging Details : All the machines are fixed and well packaged in the plywood cases.

Product name : 55 Ton High Speed Vertical Injection Molding Machine For Making Connector

Model : TFV4-55-SP

Key selling points : Stability and durability

Color : White

Function : Making plastic product

Usage : Date cable

Warranty : 12 months

Contact Now

55 Ton High Speed Vertical Injection Molding Machine For Making Data Cable

Dongguan Taifu Machinery Co., Ltd. was established in 2009 and is located in Dongguan, Guangdong Province. With a global perspective, we specialize in the manufacturing of injection molding equipment and are a vertical injection molding machine supplier that integrates design, research and development, production, sales, and service.

High speed vertical injection molding machine is one of our company's main products. Using an energy storage device, the maximum firing rate can reach 600mm/sec. Adopting imported hydraulic components and electronic control, it has fast response, high accuracy, stability, and durability.

We can customize and develop according to the actual needs of customers and provide the most precise, efficient and economical personalized combination solutions.

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

DONGGUAN TAIFU MACHINEY CO.,LTD
High Speed Machine Technical Parameters
ITEMS UNIT single cylinder injection
a b c
Screw stroke mm 80 100 100
Screw Diameter mm 16 18 20 20 22 24 22 24 26
Theoretical Injection Volume cm3 16 20 25 31 38 45 38 45 53
Injection Weight(PS) g 15 19 23 29 35 42 35 42 49
oz 0.53 0.67 0.82 1.03 1.25 1.48 1.25 1.48 1.74
Max.Injection Pressure Mpa 263 207 168 220 181 152 230 193 164
kgf/cm2 2680 2117 1715 2240 1851 1556 2343 1969 1678
Injection Rate (Standard) cm3/s 40 51 63 63 76 90 76 90 106
Injection Speed (Standard) mm/s 200 200 200
Injection Rate (High Speed) cm3/s 90 115 141 126 152 181 133 158 186
Injection Speed (High Speed) mm/s 450 400 350
Screw Speed Rotation r.p.m 10~350 10~350 10~350
Nozzle Out From Platens mm ≥45 ≥45 ≥45
Heater Power KW 3.6 3.6 4.3

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed
55 Ton Vertical Injection Molding Machine For Data Cable With High Speed55 Ton Vertical Injection Molding Machine For Data Cable With High Speed55 Ton Vertical Injection Molding Machine For Data Cable With High Speed55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

· WHO WE ARE

TAIFU Machinery is a professional manufacturer of vertical injection molding machines integrated with strong capabilities of R&D, manufacturing and services, with more than 15 years manufacturing experience; 100 employees; 15,000 square feet of manufacturing floor spaces and with facility in the Dongguan city, Guangdong province, China. We are certified by ISO9001, CE and patents 20 inventions.


We aims to supply quality products and excellent services to create value for customers on the basis of integrity, innovation, and win-win cooperation. TAIFU Machinery will be your most valuable and reliable partner in business.

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

· OFFICE AREA

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

We have 15,000 square feet of manufacturing floor space and with facilities in China. All the machines are manufactured by our own employees in our own factory.

  • FACTORY AREA ​​​
· Parts processing center

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

  • Machine assembly workshop

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

  • Warehouse

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

  • Finished product machine shop

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

  • PHOTOS OF DIFFERENT EXHIBITIONS

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

  • DELIVERY

We products and delivers more than 2,000 sets of vertical injection molding machines annually. All the machines will be packed well before shipment.

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

  • CUSTOMER SITES

We provide one-stop solutions of plastic injection molding from raw material to automation, trying to create more values for our customers.

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

For more than 15 years, we have recognized our customers as long-term partners, growing together. Take advantage of this global strength, and grow with us as we grow with you.

  • COOPERATIVE CLIENTS

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

There are wide range of vertical plastic injection molding machines (thermoplastic, rubber) we provide, including Rotary table vertical injection molding machine, Bakelite machine, BMC Machine, LSR silicone injection molding machine, C-type vertical injection molding machine, etc. Not only can we provide standard machines, but we are able to also customize machines to meet your unique needs.

  • WHAT WE DO

There are wide range of vertical plastic injection molding machines (thermoplastic, rubber) we provide, including Rotary table vertical injection molding machine, Bakelite machine, BMC Machine, LSR silicone injection molding machine, C-type vertical injection molding machine, etc. Not only can we provide standard machines, but we are able to also customize machines to meet your unique needs.

  • GROUP PHOTO OF EMPLOYEES

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

Your Professional Vertical Injection Molding Machine Manufacturer-TAIFU

We are ready to provide a well-built, high-performance products. Contact Us Now!

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

55 Ton Vertical Injection Molding Machine For Data Cable With High Speed

Q1: Are you a trading company or manufacturer?

A: We are a factory located in Dongguan city-the largest industrial manufacturing area in China. All the machines are manufactured by our own employees in our own factory.

Q2: How long is the warranty time?

A: 1 year warranty for all the machines. We provide free parts for any not man-made damages and quality problems. Our technical support will accompany with you during the machines' lifetime. If machines are operated properly, it can service more than 20 years.

Q3: What are your payment terms?
A:T/T 50% in deposite,50% before departure.


Q4: How about your delivery time?
A:Generally speaking, it will take 20 to 45 days after receiving the advance payment. The specific delivery time depends on
Regarding your order and quantity.

Q5:How do you handle packaging and shipping?

A: Our spool are plastic-lined inside and packaged in cartons for safe transportation.However,we can also customize the packaging according to your specific requirements.
