160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

Dongguan Tai Fu Machinery co., LTD
Contact Now

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

Brand Name : TAIFU

Model Number : TFWB4-160

Certification : CE, ISO9001

Place of Origin : Dongguan, China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 230 sets/month

Delivery Time : Negotiable

Packaging Details : All the machines are fixed and well packaged in the plywood cases.

Product name : 160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

Model : TFWB4-160

function : Making plastic product

Application : Glasses Frame

Clamping force : 160 Ton

Machine weight : 6.5

Color : White

Warranty : 1 year

Contact Now

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

Dongguan Taifu Machinery Co., Ltd. was established in 2009 and is located in Dongguan, Guangdong Province. With a global perspective, we specialize in the manufacturing of injection molding equipment and are a vertical injection molding machine supplier that integrates design, research and development, production, sales, and service.

The standard vertical injection molding machine is one of our company's main products. New generation large two plate ultra-low workbench standard machine, large capacity mold size and mold opening stroke, suitable for more molds.

We can customize and develop according to the actual needs of customers and provide the most precise, efficient and economical personalized combination solution.

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

Part MODEL UNIT TFWB4-160
   INJECTION UNIT Screw stroke mm 200
Screw Diameter mm 45 50 55
Theoretical Injection Volume cm3 318 393 475
Injection Weight(PS) g 296 365 442
oz 10.43 12.88 15.59
Max.Injection Pressure Mpa 218 177 146
kgf/cm2 2226 1803 1490
Positioning ring diameter mm 120
Nozzle Out From Platens mm ≥45
CLAMPING UNIT Clamping Force KN(ton) 1568(160)
QTY of Ejector pcs 1
Top bar spacing mm /
Ejector Distance mm 95
Ejector Force KN(ton) 45(4.6)
OTHERS System Pressure Mpa(kgf/cm2) 13.7(140)
Electric Power KW 22
Machine Dimensions L*W m 2.4*1.9
H m Min:2.8(Max:3.7)
Cooling water capacity L/min 50
Machine Weight ton

6.5

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

· WHO WE ARE

TAIFU Machinery is a professional manufacturer of vertical injection molding machines integrated with strong capabilities of R&D, manufacturing and services, with more than 15 years manufacturing experience; 100 employees; 15,000 square feet of manufacturing floor spaces and with facility in the Dongguan city, Guangdong province, China. We are certified by ISO9001, CE and patents 20 inventions.


We aims to supply quality products and excellent services to create value for customers on the basis of integrity, innovation, and win-win cooperation. TAIFU Machinery will be your most valuable and reliable partner in business.

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

· OFFICE AREA

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

We have 15,000 square feet of manufacturing floor space and with facilities in China. All the machines are manufactured by our own employees in our own factory.

  • FACTORY AREA ​​​
· Parts processing center

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

  • Machine assembly workshop

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

  • Warehouse

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

  • Finished product machine shop

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

  • PHOTOS OF DIFFERENT EXHIBITIONS

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

  • DELIVERY

We products and delivers more than 2,000 sets of vertical injection molding machines annually. All the machines will be packed well before shipment.

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

  • CUSTOMER SITES

We provide one-stop solutions of plastic injection molding from raw material to automation, trying to create more values for our customers.

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

For more than 15 years, we have recognized our customers as long-term partners, growing together. Take advantage of this global strength, and grow with us as we grow with you.

  • COOPERATIVE CLIENTS

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

There are wide range of vertical plastic injection molding machines (thermoplastic, rubber) we provide, including Rotary table vertical injection molding machine, Bakelite machine, BMC Machine, LSR silicone injection molding machine, C-type vertical injection molding machine, etc. Not only can we provide standard machines, but we are able to also customize machines to meet your unique needs.

  • WHAT WE DO

There are wide range of vertical plastic injection molding machines (thermoplastic, rubber) we provide, including Rotary table vertical injection molding machine, Bakelite machine, BMC Machine, LSR silicone injection molding machine, C-type vertical injection molding machine, etc. Not only can we provide standard machines, but we are able to also customize machines to meet your unique needs.

  • GROUP PHOTO OF EMPLOYEES

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

Your Professional Vertical Injection Molding Machine Manufacturer-TAIFU

We are ready to provide a well-built, high-performance products. Contact Us Now!

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

160 Ton Band Brake Standard Vertical Injection Molding Machine For Making Glasses Frame

Q1: Are you a trading company or manufacturer?

A: We are a factory located in Dongguan city-the largest industrial manufacturing area in China. All the machines are manufactured by our own employees in our own factory.

Q2: What are the advantages of the band brake standard machine?

A: The overall height of the machine is 25~30% lower than that of traditional tonnag.

Q3: What are your payment terms?
A:T/T 50% in deposite,50% before departure.


Q4: How about your delivery time?
A:Generally speaking, it will take 20 to 45 days after receiving the advance payment. The specific delivery time depends on
Regarding your order and quantity.

Q5:How do you handle packaging and shipping?

A: Our spool are plastic-lined inside and packaged in cartons for safe transportation.However,we can also customize the packaging according to your specific requirements.

If you are interested in it, please contact me without hesitation!
