120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

Brand Name : TAIFU

Model Number : TFV4-120ZT-2C

Certification : CE,ISO9001

Place of Origin : Dongguan,China

MOQ : 1 set

Price : negotiable

Payment Terms : L/C, T/T, D/A, D/P, Western Union

Supply Ability : 210 sets per month

Delivery Time : negotiable

Packaging Details : All the machines are fixed and well packaged in the plywood cases.

Product name : 120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

model : TFV4-120ZT-2C

Used for : Scraper With Handle

Function : Two color products

Application : Multi-color plastic product

Key word : High productivity

After-sales service : provided

Warranty : 12 months

Contact Now

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

Taifu vertical two-color turntable injection molding machine is specially designed for two-color and two-material injection molding. It is equipped with two sets of injection devices with independent hydraulic oil circuits. Two molds can be installed on the upper template and the turntable.

During molding, the turntable rotates 180° forward and reverse alternately to complete injection molding of two colors and two materials. It can also be used with a turret to practice automated production.

The machine is equipped with a high-performance control system to provide a strong guarantee for high-quality injection molding accuracy and stability. It is now widely used in the auto parts and new energy industries.

We can also customize machines according to your needs!

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

Machine Technical Parameters

ITEM UNIT TFV4-120ZT-2C
INJECTION UNIT
Screw stroke mm 140
Screw Diameter mm 22 26 28
Theoretical Injection Volume cm3 53 74 86
Injection Weight(PS) g 49 69 80
oz 1.75 2.44 2.83
Max.Injection Pressure Mpa 248 178 153
kgf/cm2 2531 1812 1563
Screw Speed Rotation r.p.m 10~300
Nozzle Out From Platens mm ≥45
Heater Power KW 3.6
CLAMPING UNIT
Clamping Force KN(ton) 1176(120(60*2))
Clamping Stroke mm 280
(D) Rotary Table Size mm φ1010
Ejector Distance mm 60
Ejector Force KN(ton) 17.2(1.75)
OTHERS
System Pressure Mpa(kgf/cm2) 13.7(140)
Oil Tank Capacity L 460
Electric Power KW 11+11
Machine Dimensions L*W m 2.4*2.2
H(Excluding shock-absorbing feet) m Min:2.8(Max:3.6)
Height of Workbench+(Excluding shock-absorbing feet) mm 1450+(80)
Machine Weight ton 7.3

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

WHO WE ARE

TAIFU Machinery is a professional manufacturer of vertical injection molding machines integrated with strong capabilities of R&D, manufacturing and services, with more than 15 years manufacturing experience; 100 employees; 15,000 square feet of manufacturing floor spaces and with facility in the Dongguan city, Guangdong province, China. We are certified by ISO9001, CE and patents 20 inventions. We aims to supply quality products and excellent services to create value for customers on the basis of integrity, innovation, and win-win cooperation. TAIFU Machinery will be your most valuable and reliable partner in business.

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

OFFICE AREA

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

FACTORY AREA

We have 15,000 square feet of manufacturing floor space and with facilities in China. All the machines are manufactured by our own employees in our own factory.

  • Parts processing center

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

  • Machine assembly workshop

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

  • Warehouse

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

  • Finished product machine shop

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

PHOTOS OF DIFFERENT EXHIBITIONS

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

DELIVERY

We products and delivers more than 2,000 sets of vertical injection molding machines annually. All the machines will be packed well before shipment.

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

CUSTOMER SITES

We provide one-stop solutions of plastic injection molding from raw material to automation, trying to create more values for our customers.

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

COOPERATIVE CLIENTS

For more than 15 years, we have recognized our customers as long-term partners, growing together. Take advantage of this global strength, and grow with us as we grow with you.

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

WHAT WE DO

There are wide range of vertical plastic injection molding machines (thermoplastic, rubber) we provide, including Rotary table vertical injection molding machine, Bakelite machine, BMC Machine, LSR silicone injection molding machine, C-type vertical injection molding machine, etc. Not only can we provide standard machines, but we are able to also customize machines to meet your unique needs.

GROUP PHOTO OF EMPLOYEES

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

Your Professional Vertical Injection Molding Machine Manufacturer

-TAIFU We are ready to provide a well-built, high-performance products. Contact Us Now!

120 Ton Scraper With Handle Making Machine Vertical Two Color Injection Molding Machine

Q: Are you a trading company or manufacturer?

A: We are a factory located in Dongguan city-the largest industrial manufacturing area in China. All the machines are manufactured by our own employees in our own factory.

Q: How long is your delivery time?

A: Small machines are in stock. Generally, the delivery time of standard machines is 7~35 working days. For customized machines, it will be 40~60 working days.

Q: How long is the warranty time?

A: 1 year warranty for all the machines. We provide free parts for any not man-made damages and quality problems. Our technical support will accompany with you during the machines' lifetime. If machines are operated properly, it can service more than 20 years.

Q: What are your terms of payment?

A: 50%TT in advance, 50% balance before shipment. or L/C at sight.

If you are interested in our machines, please do not hesitate to CONTACT US!
